HD10 Series Connector
Our HD10 Series connectors deliver maximum contact density in a compact size 10 shell. Designed to meet rigorous military specifications, these circular connectors provide reliable performance in demanding aerospace, defense, and industrial applications where space is at a premium.
Key Features
- Size 10 shell for compact installations
- High-density contact arrangement
- Military specification compliance
- Environmental sealing IP67/IP68
- Multiple keying options
- Operating temperature: -55°C to +175°C
Specifications
| Shell Size | Size 10 |
| Positions | Up to 24 positions |
| Current Rating | Up to 5A per contact |
| Voltage Rating | Up to 500V |
| Temperature Range | -55°C to +175°C |
| Environmental Rating | IP67/IP68 |
| Contact Material | Copper alloy with gold plating |
| Shell Material | Aluminum alloy with cadmium plating |
Applications
Military communications equipment
Aerospace avionics systems
Unmanned aerial vehicles (UAVs)
Radar and sensor systems
Electronic warfare systems
Tactical ground equipment
Why Choose Our HD10 Series
Maximum density in minimal space
Proven military-grade reliability
Lightweight aluminum construction
Competitive pricing vs OEM
